ThermaShade® - Sunshade System
System Options: Concealed Anchor
with Curtain Wall
YHC 300 OG
Insulated Glass
Square Outrigger
24" (Nominal)
click on the section cuts to view details
Consult YKK AP's Installation Instructions prior to ordering and installation of this product. Additional details and information may be obtained by calling YKK AP at 1-800-955-9551.
90 Degree Outside Corner (for 5 1/4" back depth mullions only)90 Degree Inside Corner
Jamb Outrigger ConnectionIntermediate Outrigger ConnectionLouver / Fascia
